Q10F5SZZRYG24E
The Q10F5SZZRYG24E is an LED indicator with a mounting hole diameter of 10mm. It features a flush bezel style and a stainless steel bezel finish. The rear epoxy wires serve as the terminals for easy installation. The type of illumination is tricolor, emitting red, yellow, and green LEDs. It operates at a voltage of 24VDC and has a sealing rating of IP67, ensuring protection against dust and water. The electrode configuration is common cathode.
Key Features
- Mounting Hole: 10 mm
- Voltage: 24VDC
- Sealing: IP67
- Terminals: Rear Epoxy Wires
- Bezel Finish: Stainless Steel
- Type Of Illumination: Tricolor
- Bezel Style: Flush
Specifications
Distinctive Features:
- 5 mm flush diffused LED, standard, hyper bright or water clear
- Flush chamfered bezel style(200 mm long) wire terminations
- Available in RGB
General Specifications:
- Max Reverse Voltage: 5 V
- Viewing Angle: 60° *
- Life Expectancy: 100,000 hours
- Torque: 20 to 25 cNm* Dependant on Model
Environmental Specifications:
- Panel sealed up to IP67 according to EN 60529
- Temperature Range: –40 to +85 °C (operation & storage)
Electrical Specifications:
- 02 (No Resistor) 1.8 to 3.3 VDC 20 mA max*
- 6 VDC 5.4 to 6.6 VDC 20 mA
- 12 VDC 10.8 to 13.2 VDC 20 mA
- 24 VDC 21.6 to 26.4 VDC 20 mA
- 28 VDC 25.2 to 30.8 VDC 20 mA
