QH22L28RC
The QH22L28RC is a LED indicator that features a red LED color, providing clear and visible signaling. It is designed with a sealing rating of IP67, ensuring its resistance to dust and water ingress. This makes it suitable for use in various environments, including industrial applications where durability and reliability are crucial. With its compact design and easy installation, the QH22L28RC is an ideal choice for applications that require efficient and effective visual indication.
Key Features
- Bezel Color: Black
- Sealing: IP67 (panel seal)
- Series: QH
- Size: 22 mm cutout
- Led Color: Red
- Lens Color: Tinted
Specifications
Distinctive Features:
- Single, dual and RGB colors available
- Designed to integrate with Ø16, Ø19, Ø22 and Ø30 mm panel
- cutout switches and other APEM and IDEC components
- Ø22 mm oversized version for integration with APEM’s range of
- Emergency Stop switches
- Panel sealed up to IP67
- 200 mm 26 AWG UL1061 wire terminations
General Specifications:
- Life Expectancy : 50,000 Hours
- Viewing Angle : 120°
- Max Reverse Voltage : 5VDC
Environmental Specifications:
- Panel seal to IP67
- Operating Temperature Range : -30 to +85°C
Electrical Specifications:
- 12VDC 10.8 to 13.2 10mA
- 24VDC 21,6 to 26.4 10mA
